Feature and Benifits

• Bandwidth 500MHz, 350MHz,200MHz,100MHz
• Sample Rate Analog channel up to 4 GSa/s, Digital Channel up to 1 GSa/s(MSO)
• Standard Memory depth: Analog channel up to 140 Mpts, Digital Channel up to 28 Mpts(MSO)
• 2 or 4 Analog Channels, 16 Digital channels(MSO)
• Waveform capture rate Up to 110,000 waveforms per second,
• Real Time Waveform Record, Replay & Analysis(Std. up to 200,000 frames)
• Lower noise floor, the Min. vertical sensitivity is 1mV/div
• Innovative “UltraVision” technology
• A variety of Trigger functions
• Support serial bus trigger(Std.) and decoding(Opt.) for both analog and digital channels
• Support bandwidth update for 200MHz and 350MHz bandwidth models
• Complete Connectivity: USB Host& Device, LAN(LXI-C), VGA, AUX,USB-GPIB(Opt.)
• 9 inch WVGA(800X480), 256 level intensity grading display

Advanced functions

• Large screen display , novel and beautiful appearance
• UltraVision: Up to 110K Waveforms/s Waveform capture rate
• UltraVision: Realtime waveform record,replay, analysis function (std.)
• UltraVision: Deeper Memory with Multi-Level intensity grading display
• Advanced math function (user defined)
• Mask test functions
• Automatic measurements with statistics
• Serial bus Triggering and Decoding (Support both Analog and Digital channels)
• Serial bus decoding functions : RS232/UART
• Measurement History: Show the trend of the parameters
• Mixed Signal Analysis with analog and digital channels
• Easy to be grouped and labeled for digital channels
• Serial bus triggering and decoding on digital channels
• Support a variety of logic levels
