Specyfikacja – Lighting Circuit Training kit
Technical Data
- Halogen lamp
- One of 220 V
- One of low voltage
- Fluorescent Lamp
- Four lamps 60cm
- Rated power: 18W
- Metal Halide Lamp
- Rated power: 400W
- Sodium Vapor Lamp
- Rated power: 400W
- High Discharge Lamp Auxiliary
- Magnetic ballast rated power: 400W
Scope of Delivery
- Lighting Circuit Training kit (EL – 006)
- Hard copy of the user manual
Options
Required for Operation
Technical Details
- The training kit consists of up to 13 modules which can be mixed and matched to carryout various lighting experiments.
- All of the modules contain power supply terminals and earthing terminals to receive power from the main frame.
- Using this kit, trainees will acquire knowledge regarding electrical wiring and lighting circuit designing and forming.
- The kit contains conventional sockets. This module contains a two non-earthed socket and one earthed socket.
- Multiway switches module is provided which contains two-gang one-way switch, as well as a three-gang one-way switch.
- Conventional ballast is also included since the ballast is a small device wired to the lights circuitry which restricts the amount of electrical current travelling through it.
- Electronic ballast module is provided which relies on power electronic circuit to start the fluorescent lamp. This module contains two electronic ballasts: fluorescent electronic ballast and low voltage electronic ballast.
- A module that contains a pair of two-way switches and a pair of intermediate switches is provided to allow for more lighting related experiments.
- Rotary dimmer module is provided which contains a two-way dimmer switch. This dimmer has the ability to turn ON/OFF the bulb as well as dim the intensity
- Incandescent lamp module is included in the kit. This module contains two lamps that operate on 220VAC. This lamp is dimmable and can be dimmed using the rotary dimmer.
- Plug in compact fluorescent lamp module is included of type PL and a dedicated magnetic ballast. The lamp cannot be operated without a ballast.
- Two halogen lamps are included in one module. One 220V halogen lamp and a single low voltage halogen lamp.
- Four 60cm fluorescent lamps are included in one module that can be mixed and matched in lighting experiments.
- Metal halide lamp is included, the MH lamp itself is built with two main sections — the outer bulb and the inner arc tube.
- Sodium vapor lamp module is included in the kit which contains a mixture of xenon, sodium and mercury.
- High discharge lamp auxiliary module is supplied. This module contains of one electronic ignitor and a magnetic ballast.
- The modules are well protected in a provided kit to protect against wear and deterioration.
