Opis
|
Function
|
Measurement of AC/DC current, leakage current, repairing the car circuit.
|
|
Power Supply
|
Zn-Mn dry battery,6F22,9V, continuous use for 30h
|
|
Test Mode
|
Clip-on CT, noncontact measurement
|
|
Clamp Size
|
25mmX35mm
|
|
Measurement Range
|
0mA~60.0A AC/DC
|
|
Resolution
|
1mA AC/DC
|
|
Accuracy
|
±2%rdg±5dgt (23?±5?, below 75%rh)
|
|
Display Mode
|
Four digits LCD display
|
|
Dimension
|
LWH: 168mm×65mm×34mm
|
|
LCD Dimension
|
35mm×21.5mm; display domain: 32mm×15mm
|
|
Sampling Rate
|
2 times/s
|
|
Frequency
|
AC: 45Hz-400Hz
|
|
Polarity Indication
|
DC current auto identified and display“—”
|
|
Test Position
|
Tested wire in the jaw center
|
|
Range Shift
|
Automatically
|
|
Line Voltage
|
Do not exceed AC 600V
|
|
RS232 Interface
|
Data stored in the memory of the meter via RS232 upload to PC
|
|
Com-Configure
|
Baud rate:9600, data bit:8, stop bit:1, check bit: NONE
|
|
Data Memory
|
99 units, FULL blinks when the memory is full
|
|
Reading Hold
|
DH indicating the reading is hold
|
|
Out of Range
|
OL indicating the current is out of range
|
|
Auto Power-off
|
5 Minutes after power on, it will power off automatically to lower the power consumption
|
|
Battery Voltage
|
Indicating the battery voltage is lower than 7.2V.Then the battery have to be changed.
|
|
Weight
|
180g (including the battery)
|
|
Working Current
|
10mA
|
|
Humiture
|
-10?-50?,below 80%rh
|
|
Limit Temperature Error
|
-10?-0? and 40?-50?, within 2%rdg
|
|
Humiture Storage
|
-10?-60?,below 70%rh
|
|
Insulating Strength
|
AC 3700V/rms. (between the alloy of the clamp and the housing)
|
|
Applicable safety rules
|
IEC1010-1, IEC1010-2-032, pollution:2, CAT ?(600V)
|
|
Accessories
|
Meter: 1pc; toolkit: 1pc; RS232 communication line: 1pc; disk: 1pc; case: 1pc.
|
