Opis produktu – A2.7.1.1 Ogniwa paliwowe
A2.7.1.1 Ogniwa paliwowe
| Our experimental equipment for this topic also includes new PEM fuel cells (PEM = Proton Exchange Membrane) built into the vehicle. The hydrogen (H2) is initially split into H atoms at a catalytically active electrode. After losing an electron (- pole) the proton H+ goes through the polymer membrane to the oxygen side, where water is produced as a result of electron gain (+ pole): O2 + 4 H+ + 4 e- => 2 H2O.
Higher voltages are necessary for driving motors. Therefore, like for the battery, many (currently about 200) elements, each of about 1 volt, must be connected in series close to the so-called stack. Since the corresponding energy is not completely consumed directly, a battery is necessary for intermediate storage. However, it can be significantly smaller than for a pure electric drive, for example.
|
||
The educational system consists of:
|
||
| 666 4795 | HydroStik PRO, CPS 4 | 1 |
| 666 4812 | PEM Fuel Cell Stack, CPS 4 | 1 |
| 666 4831 | Electric Load, CPS 4 | 1 |
| 666 4794 | Bubble Counter, CPS 4 | 1 |
| 666 4798 | HydroFill PRO 4 | 1 |
| 675 3400 | Water, pure, 1 l 4 | 1 |
| 726 09 | Panel frame T130, Two Level 8 | 1 |
| 500 421 | Connecting lead 19 A, 50 cm, red 4 | 3 |
| 500 422 | Connecting lead 19 A, 50 cm, blue 4 | 3 |
| 524 013S | Sensor-CASSY 2 Starter 4 | 1 |
| 666 484 | * PEM electrolysis unit, CPS | 1 |
| 521 485 | * AC/DC Power supply 0…12 V/ 3 A 4 | 1 |
| 501 46 | * Connecting lead 19 A, 100 cm, red/blue, pair 8 | 1 |
| Articles marked with * are not essential, we do however recommend them to carry out the experiment. | ||
