Opis produktu – Multimetr cyfrowy MS86
Parametry: IEC 61010-1, CAT. III 1000V and CAT.IV 600V
- Wyświetalcz 4000 cyfr
- Automatyczy i ręczny wybór zakresu √
- Wartość Rel √
- Zatrzymanie wartości Max/Min √
- Zatrzymanie pomiaru √
- Bezdotykowy wykrywacz napięcia (NCV) √
- Test Diody √
- Transistor √
- Ciągłość √
- Podświetlanie wyświetlacza √
- Zasilanie : 9V 6F22 Battery(Not Included)
- Safety Rating CE CAT III1000V
- Package size: 21 * 13 * 5cm / 8.4 * 5.2 * 2.0in
- Package weight: 540g / 1.2lb
Specification:
|
Specifications |
Range |
Accuracy MS86 |
|
| DC Voltage |
400mV/4V/40V/400V 1000V |
±(0.5%+2) ±(0.8%+2) |
|
| AC Voltage |
400mV 4V/40V/400V 750V |
±(2.0%+3) ±(0.8%+3) ±(1.0%+3) |
|
| DC Current |
400μA/4000uA/40mA/400mA 10A |
±(0.8%+2) ±(1.2%+2) |
|
| AC Current |
400μA/4000uA/40mA/400mA 10A |
±(1.5%+2) ±(2.0%+2) |
|
| Resistance |
400Ω/4kΩ/40kΩ/400kΩ/4MΩ 40MΩ |
±(0.8%+1) ±(1.0%+2) |
|
| Capacitance | 40nF/400nF/4μF/40μF/400μF/4000μF | ±(4.0%+5) | |
| Frequency | 10Hz~10MHz | ±(0.5%+2) | |
| Duty cycle | 1%~99% | ±(2.0%+2) | |
| Temperature(°C) | -20°C~1000°C | ±(2.0%+2) | |
| Feature | |||
| Display | 4000 Counts | ||
| Auto and manual range | √ | ||
| Relative Measurement | √ | ||
| Max/Min Value hold | √ | ||
| Data hold | √ | ||
| Non-Contact Voltage Detector(NCV) | √ | ||
| Diode test | √ | ||
| Transistor | √ | ||
| Continuity | √ | ||
| Back light | √ | ||
| General | |||
| Power supply | 9V 6F22 Battery | ||
| Weight | Approx 380g | ||
| Size | 188mmx92mmx50mm | ||
| Safety Rating | CE CAT III1000V | ||
Package list
- 1 * MS86 Multifunction Digital Multimeter
- 1 * Test Cable
- 1 * Temperature Test Cable
- 1 * Test Convertor
- 1 * English Instructions
- 1* Portable Bag
